Product Description
Automatic Notching Machine for Angle Steel
Basic Info
Model No.: RHD
Application: Metal
Processing Precision: ±0.05mm
Certification: CE, ISO 9001
Condition: New
Function: Notching Angle Steel
Max Angle Size: L200*200*20
Max Notching Force: 200T
Additional Info
Packaging: Wooden Pallet
Productivity: 80set
Brand: SF
Transportation: Ocean
Place of Origin: China
Certificate: ISO 9001
Port: Qingdao Port
Product Description
Angle Notching Machine is used to cut angle of angle steel in power and telecommunication tower industry.
Feature
1. Controlled by hydraulic system, with stable working and fast notching speed.
2. Equipped with typing and punch function, only need to change the notching die to punching or typing die.
3. The notching die is a right-angled, double-edged, and rotatable.By adjusting the direction of notching frame to finish different angle notching.
Parameter
| Oil cylinder pressure | 1000 KN |
| Angle size | L40×3~L160×16 mm |
| Stroke of oil cylinder | 50 min |
| Total power | 11 KW |
| Rotate angle of notching die | 360°Manual |
| Size of notching die | 700×700×500 mm |
| Volume of oil tank | 350 L |
| Weight | 3 T |
| Dimension | 1300×1020×1880 mm |
